The BT-3020-X insertion thermal mass flow meter uses a dual platinum wire wound sensor enclosed in an SS316 sheath, ensuring accurate gas flow measurement. Its advanced sensor design features two platinum coils that work as heating and temperature-sensing elements for high accuracy.
It comes in integrated and remote transmitter versions with a graphical LCD showing temperature, velocity (nm/s), cumulative values, and real-time flow. Connectivity options include 4–20 mA HART, RS485, and pulse outputs. A flameproof enclosure and dual power inputs (24 VDC / 230 VAC) ensure safe operation in hazardous environments.
The meter includes an integrated diagnostic system for continuous performance monitoring. Its insertion design allows easy installation with 3/4” or 1” NPT compression fittings and supports pipe sizes from 2” to 80” with different probe lengths. With no moving parts, it offers long life and simple maintenance.
The BT-3020-X is suitable for clean gases like air, natural gas, LPG, biogas, and flare gases, making it ideal for precise industrial gas monitoring.
BT-3020-X Features
Graphical LCD for flow, cumulative, velocity, temperature
4–20 mA HART analog output
Dual-chamber die-cast aluminum enclosure
3/4” OD probe for easy installation
SS316 construction with no moving parts
Dual power input (24 VDC / 230 VAC)
Field programmable
Optional IoT monitoring
Explosion-proof & weatherproof enclosure
BT-3020-X Benefits
Direct mass flow measurement
High accuracy
Negligible pressure drop
Works with many gases
High turndown ratio (up to 100:1)
Unaffected by pressure/temperature changes
No moving parts
Rugged design
Easy installation
Fast response time
Mechanical Specifications
Measuring principle: Calorimetric (CTA)
Sensor: Dual RTD platinum wire wound, SS316
Probe: SS316
Fittings: 3/4″ NPT or 1″ NPT
Ferrule: PEEK
Pipe sizes: DN50–DN2000
Probe lengths: 6”–80”
Wetted parts: SS316
Housing: Dual-chamber die-cast aluminum
Flow conditioner: Optional
Transmitter Specifications
Display: Graphical LCD
Parameters: Flow, cumulative, velocity, temperature
Electronics: Microprocessor-based
Configuration: Keypad
Outputs: 4–20 mA HART
Communication: RS485 Modbus RTU
Power: 24 VDC (2A) / 230 VAC
Cable entry: 1/2” NPT(F)
Enclosure: Flameproof Ex’d’ IIB T6, EPL Gb/Db
Approvals: PESO
Process Parameters
(Same as mechanical)
Calorimetric principle
Dual RTD platinum sensor, SS316
3/4” or 1” NPT fitting
PEEK ferrule
DN50–DN2000 pipe sizes
6”–80” probe lengths
SS316 wetted parts
Die-cast aluminum housing
Optional flow conditioner
